PETRO Industrial Solar Panel Kits

PETRO Industrial's Solar Panel Kits

Do you need power to dispense fuel from your storage tank on a remote location with no electricity?

PETRO's Solar Panel Kits can be installed on Trailers or Self Bunded Tanks to power 12V DC Pump kits.



THE KIT COMPONENTS ARE:

• 2 x   CNPV 50W 12V Solar Panel.
• 1 x   Regulator 12V 10amp - PWMLVD.
• 1 x   Volt Meter 10V-16V Expanded Scale.
• 1 x   Fuse 10amp Plastic Circuit Breaker.
• 4 x   Cable Gland 5-10mm Carroll.
• 10 x   Connectors.
• 2 x   Brackets to suit Solar Panel.
• 4 x   Cable 6mm Sq-C25.
• 4 x   Convoluted Tube 13mm - CT13.
• 2 x   Fuse 10amp.
• 1 x   Ritar 12V 120Ahr Deep Cycle Battery.
• 1 x   Large Battery Box.
• 1 x   12V Automatic Battery Charger 2/4/8 AMP.

SCORPION SGP-50W POLY SOLAR PANEL:
Nominal Peak Power of 50W or 100W

RA12-1205 RITAR BATTERY (12V1 / 15Ah):
RA series is a general purpose battery with 10 years design life in float service. It meets with IEC, JIS and BS standards .With up-dated AGM valve regulated technology and high purity raw materials, the RA series battery maintains high consistency for better performance and reliable standby service life. It is suitable for UPS/EPS, medical equipment, emergency light and security system applications.

BLUE SMART – IP65 12V BATTERY CHARGER:
With up to 95% efficiency, these chargers generate up to four times less heat when compared to the industry standard. And once the battery is fully charged, power consumption reduces to 0,5 Watt, some five to ten times better than the industry standard.

MORNINGSTAR SUNSAVER SOLAR CONTROLLER:
Extremely High Reliability

• Failure rate of less than 1 per 1,000 shipped (<0.1%).
• 100% solid state. Power MOSFET design.
• Manufactured in an ISO 9000 factory.
• 100% pre-shipment functional testing.

Longer Battery Life

• Advanced PWM charging.
• Series design (not shunt) for cool operation.
• 4-stage charging: bulk, absorption, float, equalize.
• Optimized sealed or flooded battery set points.
• Temperature compensated charging.
• Low voltage load disconnect on several versions.

VICTRON CONNECT APP:
Setup, readout and configure your Blue Smart IP65 Charger via your smartphone. You can display the status of your charger and battery and even control the functions of your charger using the VictronConnect app. On your screen the readout of voltage and current is default available.

DOWNLOAD THE DATA SHEET:

https://cdn.shopify.com/s/files/1/2377/5935/files/Solar_Panel_Kit_DataSheet_May_2019.pdf?782
